Issue 2.0

SV9100 Networking Manual 5-7

The following table shows the LED indication when transmitting or receiving

data on CN1.

Table 5-2 VOIPDB LED CN1 Transmit/Receive Data Indications

LED

Link Up

Auto Negotiation Mode Force Mode

1000M

bps

100Mbps 10Mbps

1000M

bps

100Mbps 10Mbps

Half Full Half Full Half Full Half Full

ACT (LED A)

ON ON ON ON ON ON ON ON ON ON

LINK1000 (LED 1G)

ON OFF ON OFF ON ON OFF ON OFF ON

LINK 100 (LED 100)

ON OFF OFF OFF OFF ON OFF OFF OFF OFF

LINK10 (LED 10)

OFF ON ON OFF OFF OFF ON ON ON ON
