NEC Univerge SV9100 User Manual

SV9100 Networking Manual I-1
UNIVERGE
®
SV9100
Introduction
SECTION 1 GENERAL OVERVIEW
This manuals provides information for networking for the UNIVERGE SV9100
systems. Networking can be accomplished using one of the following methods:
 SV9100 K-CCIS (US Only)
 SV9100 IP K-CCIS
 SV9100 NetLink
SECTION 2 MANUAL ORGANIZATION
This manual is divided into two books to describe the networking functions: the K-
CCIS networking/K-CCIS IP networking and IP networking.
SECTION 3 COMMON TERMS
The following terms and the associated abbreviations or alternate nomenclature may
be found throughout this document.
IMPORTANT
When the GPZ-IPLE daughter board is installed, half-duplex connections are not supported. For
troubleshooting purposes, a managed switch capable of port mirroring is required to capture
packet data from the SV9100 IPLE Ethernet port.
Table I-1 Common Terms and Associated Abbreviations
Term Abbreviation Description
GCD-CP10 GCD-CP10
SV9100 CPU
CPU
SV9100 CPU
GPZ-IPLE VOIPDB
VOIP Daughter Board
VoIP Daughter Board, mounted on
GCD-CP10

NEC Univerge SV9100 Specifications

General

VoIP Support	Yes
VoIP Protocols	SIP, H.323
Voicemail	Integrated voicemail
Networking	Yes, via IP
Unified Communications	Yes
Mobility	Supports mobile extensions and applications
Type	IP-PBX
Network Interfaces	Gigabit Ethernet
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Weight	Varies depending on chassis and expansion cards
