Issue 2.0
5-44 SV9100 IP K-CCIS
SECTION 6 SERVICE CONDITIONS
For InMail remote CCIS extensions are not supported in a centralized directory.
DT800/DT700 terminals are supported for Peer-to-Peer connections via a P2P
CCIS call.
Standard SIP terminals are not supported for Peer-to-Peer connection.
If either Programs15-05-50 or 50-15-04 are set to 0 (Disable) in system A, Peer-to-
Peer is disabled for system A and any remote systems when calling system A.
When port translation is done through a NAT router, Peer-to-Peer is disabled.
When RTP encryption is enabled, Peer-to-Peer is disabled.
When connecting to other SV9100s using CCISoIP, Program 84-34-01 (Type 5
CCIS) must be set the same in all systems.
SV9100 K-CCIS-IP to another SV9100, for calls from an IP terminal to a TDM
terminal/trunk via Peer-to-Peer, the IP Terminal's CODEC must match the CCIS
CODEC and the packet size is auto negotiated based on the receiving sides packet
size.
SV9100 K-CCIS-IP to another SV9100 or to a NEAX PBX (SV9300, SV9500, etc.),
for calls from an IP terminal to another IP terminal/trunk via Peer-to-Peer, the IP
Terminal’s CODEC must match and the packet size is auto negotiated.
SV9100 K-CCIS-IP to a NEAX PBX (SV9300, SV9500, etc.), for calls from an IP
terminal to a TDM terminal via Peer-to-Peer, the IP Terminal's CODEC and packet
size (Program 84-24-XX) need to match the NEAX PBX CCIS CODEC and packet
size settings.
For this feature, the GPZ-IPLE is installed on the GCD-CP10. Only one GPZ-IPLE
can be installed per system for a maximum of 256 VoIP resources.
The audio quality of speech connections depends on the available bandwidth
between the GPZ-IPLE daughter boards in the data network. As Internet is an
uncontrolled data network compared to an intranet, using this application in intranet
WAN environment with known, or controlled and assured, Quality of Service (QoS),
is highly recommended.
The GCD-CCTA blade is not required to support this feature. It can be installed and
used in a system using traditional K-CCIS with point to point T1 lines allowing both
IP K-CCIS and traditional K-CCIS to be used with the same system.
The LAN connection is provided by a 10 Base-T/100 Base-TX/1000 Base-T, Auto
sensing, full duplex Ethernet.
If single lines for fax machines are set to Special (PRG 15-03-03), faxing across IP
CCIS will always use G.711 CODEC.
SV9100 to SV9100, IP terminal to TDM via Peer-to-Peer, the IP Terminal's CODEC
must match the CCIS CODEC and the packet size will be auto negotiated based on
the receiving sides packet size.
