Issue 2.0
5-20 SV9100 IP K-CCIS
SECTION 2 UNIVERGE SV9100 CHASSIS PROGRAMMING
The following data programs are used when installing the GPZ-IPLE daughter board
for UNIVERGE SV9100 IP (K-CCIS).
If any address or NIC setting is changed, the system must be reset for the changes to take
affect.
2.1 Digital Trunk Assignment
Use these programs to make digital trunk assignments when an IPLE daughter
board is installed. .
Table 5-7 Digital Trunk Assignments
Program/
Item No.
Description/Selection Assigned Data Comments
10-68-01
IP Trunk Availability -
Trunk Type
0 = None
1 = SIP
2 = H.323
3 = CCIS
Default is 0
Define the IP Trunk Type
10-68-02
IP Trunk Availability -
Start Port
0 ~ 400
Default is 0
Assign the Start Port for
IP Trunks.
10-68-03
IP Trunk Availability -
Number of Ports
0 ~ 400
Default is 0
Define the number of
ports.
10-12-03
GCD-CP10 Network
Setup – Default Gateway
0.0.0.0 ~ 126.255.255.254
128.0.0.1 ~ 191.255.255.254
192.0.0.1 ~ 223.255.255.254
Default is 0.0.0.0
Assign the Default
Gateway for the
GCD-CP10.
When using the IPLE,
the IP Address and
Subnet Mask in
PRG 10-12-01 and
PRG 10-12-02 remain
default.
10-12-09
GCD-CP10 Network
Setup – IP Address
0.0.0.0 ~ 126.255.255.254
128.0.0.1 ~ 191.255.255.254
192.0.0.1 ~ 223.255.255.254
Default is 0.0.0.0
Assign the IP Address of
the IPLE.
10-12-10
GCD-CP10 Network
Setup – Subnet Mask
255.255.0.0
Default is 255.255.0.0
Assign the Subnet Mask
of the IPLE
To Next Page
