Issue 2.0
8-8 IP Multiline Station (SIP)
SECTION 7 MISCELLANEOUS
7.1 System Tones and Ring Tones
IP Phones do not use Program 80-01: Service Tone Setup entries. The tones are
generated locally by the IP telephone. When a Door Box chime rings an IP
telephone, the system activates the chimes using a ring command. Because of
this, if the volume is adjusted while the door chime is sounding, the ringing volume
of the IP Phone is adjusted.
7.2 Music on Hold
In addition, Music on Hold is provided by the IP telephone. The settings in
Program 10-04: Music on Hold Setup are ignored except to determine whether or
not music is to be provided. If 10-04-02 is set to 0, no Music on Hold is heard. If
10-04-02 is set to 1 or 2, music is provided by the IP telephone.
SECTION 8 CONFIGURATION EXAMPLES
8.1 IP Addressing
When using a GPZ-IPLE, only 1 IP Address is needed for all DSP's. It should be
the same subnet of the IP defined in 10-12-09.
The following chart shows the minimum and maximum number of IP addresses
used with different GPZ-IPLE card configurations.
Card
Minimum IP
Addresses
Maximum IP
Addresses
Notes
GPZ-IPLE 1 2
The number of DSP channels
depends on the VOIP license
loaded to GCD-CP10 up to 256.
