SV9100 Networking Manual 9-13
SECTION 5 PROGRAMMING
5.1 Configure VoIPDB Networking Information
The VoIPDB should be connected to the same IP Subnet as the GCD-CP10. It
also requires a valid IP address. Use these programs to assign VoIPDB network
related information.
 If any IP Address or NIC setting is changed, the system must be reset for the
changes to take affect.
Program
Number
Program Name Description/Comments Assigned Data 1 2 3
10-12-03
GCD-CP10 Network
Setup –Default
Gateway
Assign the IP Address for
the Router.
0.0.0.0 ~ 126.255.255.254
128.0.0.1 ~ 191.254.255.254
192.0.0.1 ~ 223.255.255.254
Default is 0.0.0.0
X
10-12-09
GCD-CP10 Network
Setup – IP Address
Assign the IP Address of
the VoIPDB.
0.0.0.0 ~ 126.255.255.254
128.0.0.13~191.255.255.254
192.0.0.1~223.255.255.254
Default is 172.16.0.10
X
10-12-10
GCD-CP10 Network
Setup –Subnet Mask
Assign the Subnet Mask of
the VoIPDB.
255.255.0.0
Default is 255.255.0.0
X
10-68-01
IP Trunk Availability
– Trunk Type
Assign the H.323 Trunk
Availability.
0 = None (Default)
1 = SIP
2 = H.323
3 = CCIS
X
10-68-02
IP Trunk Availability
– Start Port
Assign the start port
number of H.323 Trunks.
Range: 0~400
Default is 0
X
10-68-03
IP Trunk Availability
– Number of Ports
Assign the Number of
H.323 Trunks
Range: 0~400
Default is 0
X
