Issue 2.0

9-20 IP Single Line Telephone (SIP)

5.2 SIP Phone Example

The following example show a SIP phone attached to an SV9100 system.

15-05-49

IP Telephone Terminal Basic

Setup - Receiving SIP INFO

Determines whether

SIP INFO messages

are received by the

system.

0 = Disable

1 = Allowed any time

2 = Allowed while RTP is

not available

Default = 1

Program

Number

Program Name

Description/

Comments

Assigned Data 1 2 3

SIP Phone

GCD-CP10

VoIP

Managed Switch

UNIVERGE SV9100

GCD-CP10 192.168.1.20

VoIP DSP: 192.168.1.21

Subnet Mask:255.255.255.0

Default Gateway:192.168.1.254

SIP Soft Phone
