NEC Univerge SV9100 User Manual

Issue 2.0
SV9100 Networking Manual 1-15
 Data Assignment for System A
 Data Assignment for System B
 Data Assignment for System C
 Data Assignment for System D
3.7 Determining Circuit Identification Code (CIC)
The GCD-CCTA trunk must distinguish between Voice Path and Common
Signaling channel. The trunks using Voice Path are assigned a CIC number for
each T1 trunk. The CIC numbers must match those in the connected system.
Refer to Figure 1-15 Circuit Identification Codes (CIC). The maximum value of a
CIC that can be assigned is 127.
PRG
CCIS
Route ID
Point Code Remarks
50-03-01 None None It is unnecessary to assign system
data for this office.
PRG
CCIS
Route ID
Point Code Remarks
50-03-01 1 00001 Assign the data to create a link
between Office A and Office B
using the CCH1 and a link
between Office B and C using
CCH2.
2 00003
2 00004
PRG
CCIS
Route ID
Point Code Remarks
50-03-01 1 00001 Assign the data to create a link
between Office B and Office C
using the CCH1 and a link
between Office C and D using
CCH2.
1 00002
2 00004
PRG
CCIS
Route ID
Point Code Remarks
50-03-01 None None It is unnecessary to assign system
data for this office.

NEC Univerge SV9100 Specifications

General

VoIP Support	Yes
VoIP Protocols	SIP, H.323
Voicemail	Integrated voicemail
Networking	Yes, via IP
Unified Communications	Yes
Mobility	Supports mobile extensions and applications
Type	IP-PBX
Network Interfaces	Gigabit Ethernet
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Weight	Varies depending on chassis and expansion cards
