Issue 2.0
8-66 IP Multiline Station (SIP)
Network Settings
DHCP Mode – DHCP Disable. Click OK.
IP Address – Enter the IP Address for the station, and click OK.
Default Gateway – Enter the Default Gateway Address, and click
OK. If you are testing without a router/gateway, this must be left at
the default 0.0.0.0
Subnet Mask - Enter the Subnet Mask for the station, and click
OK.
SIP Settings
SIP User – Intercom Number
Enter the extension number for the IP station, and click OK.
Server Address & URI – 1st Server Address
Enter the IP address assigned in command 10-12-09, and click
OK.
SIP Server Port - 1st Server Port
Enter port 5080, and click OK.
Press the EXIT key until you are back at the Main menu.
Press the SAVE key and the phone saves the configuration to
memory, reboots itself and registers with the CPU.
15.8.2 Automatic Registration
Follow these steps for automatic registration.
1. Steps 1 ~3 are the same as for Plug and Play mode. Step 4 is
not optional and MUST be assigned when using Automatic
Registration.
❍ The station does not require an Ethernet connection to
enter program mode. Only power is required. Power
can be provided by an AC adapter plugged into the
phone or by POE provided by a data switch. If the data
switch is providing POE it must be using the 802.3af
standard.
For Basic bench testing only the following assignments
are required:
1 Press 0 on the dial pad for configuration mode.
You are prompted with a User Name and Password.
The defaults are:
User Name: ADMIN
Password: 6633222
The user name should already be entered in the
terminal.
2 Press Set soft key to step down to the password field.
3 After you enter the password, press OK soft key.
