NEC Univerge SV9100 User Manual

Issue 2.0
SV9100 Networking Manual 2-3
SECTION 4 EXAMPLE CONFIGURATIONS
4.1 Network Configurations
Figure 2-1 Example IP Network Configuration shows four sites networked via IP
trunks. Each site has a Point Code and an IP address.
The programing for Office A and C is shown below. This would be sufficient
programming to make a call from Office A to Office C.
Figure 2-1 Example IP Network Configuration
IP Address (GCD-CP10):
192.168.1.10
Point Code: 00001
Ext. 1000 Ext 1100
UNIVERGE SV9100
Office A
IP Network
(Intranet)
Ext. 1200
IP Address (GCD-CP10):
192.168.1.20
Point Code: 00002
UNIVERGE SV9100
Office B
Ext. 1300
IP Address: 192.168.1.30
Point Code: 00003
PBX
Office C
Office D
IP Address: 192.168.1.40
Point Code: 00004
PBX

NEC Univerge SV9100 Specifications

General

VoIP Support	Yes
VoIP Protocols	SIP, H.323
Voicemail	Integrated voicemail
Networking	Yes, via IP
Unified Communications	Yes
Mobility	Supports mobile extensions and applications
Type	IP-PBX
Network Interfaces	Gigabit Ethernet
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Weight	Varies depending on chassis and expansion cards
