Issue 2.0

SV9100 Networking Manual 8-71

Follow these steps for manual registration.

Steps 1~4 are the same as for Section 15.8.2 Automatic Registration on

page 8-66.

1. Same as for Automatic Registration Mode.

2. Same as for Automatic Registration Mode.

3. Same as for Automatic Registration Mode.

4. Same as for Automatic Registration Mode.

5. Program10-46 – ChangeProgram10-46-01 to Manual.

6. Same as for Automatic Registration Mode.

7. Same as for Automatic Registration Mode.

8. The SIP MLT Station requires assignments to be made in the phone

itself. Enter the Program Mode in the station using the following steps.

Figure 8-45 Manual Registration
