Issue 2.0
2-6 IP Networking
4.2.3 VoIP Address Assignments
Use the table below to make the appropriate assignments for VoIPDB
(GPZ-IPLE) addresses.
4.2.4 CCIS Availability
Use the table below to make the appropriate assignments for CCIS
availability.
4.2.5 IP CCISoIP Assignment
Use the table below to make the appropriate assignments for CCIS over IP.
Program/
Item No.
Description/
Selection
Assigned Data Comments
84-26-01
IPLE Basic Setup – IP
Address
XXX.XXX.XXX.XXX Assign the IPLE IP
Address
Default:
Slot 1 = 172.16.0.20
84-26-02
IPLE Basic Setup – RTP
Port Number
0~65534 Default:
RTP Port = 10020
84-26-03
IPLE Basic Setup –
RTCP Port Number
(RTP Port Number + 1)
0~65534 Default:
RTCP Port = 10021
System A System B
Program 50-01-01
Select Option 1 (Enable)
Enables the CCIS Feature
Program 50-01-01
Select Option 1 (Enable)
Enables the CCIS Feature
Program 50-02-03
Assign Route ID 9 = 01
(Route ID 9 is designated for Host
Originating Point Code)
Program 50-02-03
Assign Route ID 9 = 02
(Route ID 9 is designated for Host
Originating Point Code)
Program/
Item No.
Description/
Selection
Assigned Data Comments
50-03-01
CCIS Destination System
Settings –
Destination Point Code
0~16367 seconds
Default is 0
PRG 50-03 assignments are
only used for CCISoIP.
50-03-03
CCIS Destination System
Settings –
IP Address (IP only)
xxx.xxx.xxx.xxx
(xxx = 0~255)
Default is 0.0.0.0
PRG 50-03 assignments are
only used for CCISoIP.
50-03-04
CCIS Destination System
Settings – Point Code
Availability
0:Disable
1:Enable
Default is 1
To Next Page
