NEC Univerge SV9100 User Manual

Issue 2.0
7-4 H.323 Trunking
2.2.2 Configure VoIPDB Networking Information
Use the following programs to assign VoIPDB network configuration
information.
2.2.3 VoIPDB (DSP) Basic Setup
Use the following programs to assign VoIPDB (DSP) basic setup
information.
Table 7-2 VoIPDB Network Configuration Assignments
Program/
Item No.
Description/
Selection
Assigned Data Comments
10-68-01
IP Trunk Availability – Trunk
Type
0: None
1: SIP
2: H.323
3: CCIS
Assign the H.323 Trunk Availability
10-68-02
IP Trunk Availability – Start
Port
Range: 0 ~ 400
Default is 0
Assign the start port number of H.323
Trunks
10-68-03
IP Trunk Availability –
Number of Ports
Range: 0 ~ 400
Default is 0
Assign the Number of H.323 Trunks
Table 7-3 VoIPDB (DSP) Basic Assignments
Program/
Item No.
Description/
Selection
Assigned Data Comments
84-26-01
IPL Basic Setup – IP Address Default = 172.16.0.20 When installing GPZ-IPLE in
UNIVERGE SV9100 system, only 1
IP address is assigned.
84-26-02
IPL Basic Setup – RTP Port
Number
0~65534
Default = 10020
Assign the RTP Port Number.
84-26-03
IPL Basic Setup – RTCP Port
Number
(RTCP Port Number + 1)
0~65534
Default = 10021
Assign the RTCP Port Number.

NEC Univerge SV9100 Specifications

General

VoIP Support	Yes
VoIP Protocols	SIP, H.323
Voicemail	Integrated voicemail
Networking	Yes, via IP
Unified Communications	Yes
Mobility	Supports mobile extensions and applications
Type	IP-PBX
Network Interfaces	Gigabit Ethernet
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Weight	Varies depending on chassis and expansion cards
