SV9100 Networking Manual 5-13

The following table shows the 8 bit ToS field and the associated Diffserv

bits.

Assignments for the IP Precedence/Diffserv values in the system are submitted in

command 84-10.

RTP/RTCP = voice packets

CCIS= signaling packets

Table 5-6 ToS Field with Diffserv sBits

Diffserv Diffserv Diffserv Diffserv Diffserv Diffserv

Not

Used

Not

Use

1(on) here =

value of 32

1(on) here =

value of 16

1(on) here =

value of 8

1(on) here =

value of 4

1(on) here =

value of 2

1(on) here =

value of 1

Figure 5-7 System Data 84-10 ToS Setup
