2.3 Configure Signaling Information (H.323)
H.323 requires a gatekeeper to be configured to manage registration of H.323
endpoints. The UNIVERGE SV9100 has a built-in H.323 gatekeeper and also
supports connection to an external gatekeeper. In most cases, the SV9100
internal Gatekeeper is sufficient. External gatekeepers are used usually only in
very large H.323 networks.
To configure the UNIVERGE SV9100 to use its internal Gatekeeper, set Program
10-17-01 to Manual, and then set the GCD-CP10 IP address (Program10-12-09)
as the gatekeeper address in Program 10-17-02.
The UNIVERGE SV9100 has to register an Alias address with the gatekeeper.
This is used to route incoming calls to the correct destination.
2.3.1 H.323 GateKeeper Setup
Use the following programs to assign H.323 GateKeeper setup information.
Table 7-4 H.323 GateKeeper Setup Assignments
Program/
Item No.
Description/
Selection
Assigned Data Comments
10-17-01
H.323 Gatekeeper Setup –
Gatekeeper Mode
0 = No Gatekeeper
1 = Automatic
2 = Manual
Default is 0
Set IP Address either
automatically or manually if using an
external
Gatekeeper.
If Automatic Gatekeeper is selected,
the system searches for the
gatekeeper. If Manual Gatekeeper is
selected, the IP address defined in
Program 10-17-02 is used.
10-17-02
H.323 Gatekeeper Setup –
Gatekeeper IP Address
0.0.0.0 ~ 126.255.255.254
128.0.0.1 ~ 191.255.255.254
192.0.0.1 ~ 223.255.255.254
0.0.0.0
Default is 0.0.0.0
If Program 10-17-01 is set to 2, enter
the IP address of the Gatekeeper.
This should match the entry made in
Program 10-12-09.
To Next Page
