NEC Univerge SV9100 User Manual

Issue 2.0
SV9100 Networking Manual 8-21
11.4 DHCP Server Setup Windows Server
This section provides instructions for defining vendor classes and setting
Defining Vendor Classes
1. In the DHCP server highlight the server machine on the left side. Right click
on the server and select Define Vendor Classes.
2. Click ADD.
3. Display Name = NECDT800/DT700
4. Description = auto config
5. In the same window there is a section that shows ID, Binary, and ASCII.
Click under ASCII.
6. Enter NECDT800/DT700. This should have also added 4E 45 43 44 54 37
30 30 under the binary section.
7. Click OK and close.
Setting Predefined Options
1. Highlight the server again. Then right click and select Set Predefined
Options.
2. Change the option class to NECDT800/DT700.
3. Click ADD, and provide the following information:
 Name = FTP Address
 Data Type = IP address
 Code = 141
 Click OK, and start the process over again.
4. Click ADD, and provide the following information:
 Name = Auto Config File Name
 Data Type = String
 Code = 151
5. Click on ADD, and give the following information:
 Name = Download Protocol
 Data Type = Byte
 Code = 163
6. Click OK.

NEC Univerge SV9100 Specifications

General

VoIP Support	Yes
VoIP Protocols	SIP, H.323
Voicemail	Integrated voicemail
Networking	Yes, via IP
Unified Communications	Yes
Mobility	Supports mobile extensions and applications
Type	IP-PBX
Network Interfaces	Gigabit Ethernet
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Weight	Varies depending on chassis and expansion cards
