Issue 2.0
13-8 AspireNet
2.3.1 System IP Address
° 10-12-09 : GCD-CP10 Network Setup - IPL IP Address (IPLE)
Select the IP address of the IPLE Blade (default: 172.16.0.10). A static IP address is required. Each SV9100
system within the network must have a unique IP address.
The system must be reset in order for the change to take effect.
° 10-12-10 : GCD-CP00 Network Setup - Subnet Mask (IPLE)
Select the Subnet Mask to be used by the IPLE Blade (default: 255.255.0.0).
Example:
2.3.2 IPLE Card IP Address
° 84-26-01 : IPLE Basic Setup - IP Address (DSP)
.
Example:
Item
No.
Item Input Data Default Conditions
09 IP
Address
(IPLE)
1.0.0.1 - 126.255.255.254
128.1.0.1 -191.254.255.254
192.0.1.1 - 223.255.254.254
172.16.0.1
0
Set for IPLE.
10 Subnet
Mask
(IPLE)
128.0.0.0
240.0.0.0
254.0.0.0
255.192.0.0
255.252.0.0
255.255.128.0
255.255.248.0
255.255.255.0
255.255.255.224
255.255.255.252
192.0.0.0
248.0.0.0
255.0.0.0
255.224.0.0
255.254.0.0
255.255.192.0
255.255.252.0
255.255.255.128
255.255.255.240
255.255.255.254
224.0.0.0
252.0.0.0
255.128.0.0
255.248.0.0
255.255.0.0
255.255.224.0
255.255.254.0
255.255.255.192
255.255.255.248
255.255.255.255
255.255.0.
0
Set for IPLE.
System – A System – B
IP Address: 172.16.0.10 IP Address: 172.16.0.11
Subnet Mask: 255.255.0.0 Subnet Mask: 255.255.0.0
Slot Number 1
Item Input Data Default Description Related Program
IP
Address
1.0.0.1–126.255.255.254
128.1.0.1–191.254255.254
192.0.1.1–223.255.254.254
Slot 1: 172.16.0.20 Assign the IP address for
each DSP on the GPZ-
IPLE.
System – A System – B
IP Address: 172.16.0.20 IP Address: 172.16.5.20
Subnet Mask: 255.255.0.0 Subnet Mask: 255.255.0.0
