Issue 2.0
10-12 SV9100 NetLink
Data switches must be manageable
Routers must provide QOS
Adequate bandwidth for estimated VoIP traffic
Depending on how QoS policies are built in the network,
assignments may be needed in the CPU.
Table 10-1 VoIP Resource Chart
The number of conference blocks in a NetLink network is the same as
a stand-alone system.
Invalid data is displayed in the LCD of the terminal if Program 51-01
is enabled.
The SV9100 can recognize what system that each DT800/DT700
extension(s) are connected to and provide an ARS COS based on the
System (System ID) when using NetLink.
When NetLink is enabled synchronous ringing (PRG 14-02-17)
automatically is disabled. Synchronous ringing is not supported in a
NetLink environment.
Restrictions:
The number of total ports depends on the Primary System.
System ID (Program 51-01-02) must be unique for each system in a
NetLink network.
ACD/MIS can connect to the Primary (Main) site only.
Only one Voice Mail can be installed in a NetLink network.
Primary System Secondary 1 Secondary 2
TDM
Terminal
IP Terminal
(DT800/
DT700)
CO
Analog
/Digital
IP
Trunk
TDM
Terminal
CO
Analog
/Digital
TDM
Terminal
CO
Analog
/Digital
Primary
System
TDM
Terminal
0 P:1 0 P:1 P:1
S1:1
P:1
S1:1
P:1
S2:1
P:1
S2:1
IP Terminal
(DT800/
DT700)
P:1 0 P:1 P:1 S1:1 S1:1 S2:1 S2:1
Secondary
System 1
TDM
Terminal
P:1
S1:1
S1:1 P:1
S1:1
P:1
S1:1
00P1:1
S2:1
S1:1
S2:1
Secondary
System 2
TDM
Terminal
P:1
S2:1
S2:1 P:1
S2:1
P:1
S2:1
S1:1
S2:1
S1:1
S2:1
00
P = Primary
S1 = Secondary System #1
S2 = Secondary System #2
