Issue 2.0

SV9100 Networking Manual 3-7

If the client PCs are now connected to the network (and restarted), they should be

assigned an IP address in the range 192.168.1.50 to 192.168.1.150, a subnet

mask of 255.255.255.0 and a default gateway of 192.168.1.254. When the server

tries to obtain an IP address, the inDHCP server allocates IP address

192.168.1.32, as it is statically assigned to the server MAC address.

Figure 3-4 TCP/IP Properties Screen
