Issue 2.0
SV9100 Networking Manual 3-3
1.2 CCIS Assignment
Use these programming assignments to set the availability of CCIS.
Table 3-2 CCIS Programming Assignments
Program/
Item No.
Description/
Selection
Assigned Data Comments
50-01-01
CCIS System Setting –
CCIS Availability
0=Disable
1=Enable
Default is 0
Any CCIS settings lose
functionality if this setting is set
to 0.
50-02-01
Connecting System
Settings – Port Number of
Common Signaling
C h a n n e l ( T 1 )
0~400
Default is 0
Specify the Trunk port to send
D-channel information. This
program is available for using
DTI package.
50-02-02
Connecting System
Settings – Common
Signaling Channel Data
Speed Assignment (T1)
0=64Kbps
1=56Kbps (Default)
2=48Kbps(1)
3=48Kbps(2)
Default is 1
If 56K K-CCIS is used (1), 24
Multi-Frame (ESF) must
be assigned in PRG 10-03-02.
50-02-03
Connecting System
Settings – Originating
Point Code
0 ~ 16367
Default is 0
Default settings for each CCIS
Route ID is not assigned.
This Program is for DTI Only
and must be the same for all
CCIS Route IDs.
50-02-04
Connecting System
Settings – Destination
Point Code (T1)
0 ~ 16367
Default is 0
DPC must be what
the OPC is on the
opposite side of the
link.
50-02-05
Connecting System
Settings – Calling Name
Indication (T1)
0=Disable
1=Enable
Default is 1
Enable to receive name display
across K-CCIS.
50-04-01
CCIS Office Code
Assignment – CCIS Office
Code
Assign up to four
digits.
Default is No Setting
Only used in an open
numbering plan network. This
should include the Trunk
Access Code and Office Code
number.
14-14-01
CCIS Trunk CIC
Assignment – Trunk
Group Number 1~200
0 = Not Assigned
1~127 = CIC Numbers
Default is 0
Assign a Circuit Identification
Code (CIC) number to each
trunk number used for voice
channel.
