NEC Univerge SV9100 User Manual

Issue 2.0
SV9100 Networking Manual 5-41
3.2.3 CCH Assignment
This example shows CCH assignments for systems A, B and C.
Program 22-02-01
Trunks 9
~ 32
Assign LK 6 (Tie Line)
Program 10-40-04
Assign Number of Ports for
CCIS for Slot 1 = 24
Program 22-02-01
Trunks 5
~ 28
Assign LK 6 (Tie Line)
Program 34-01-01
Trunks 9
~ 32
Assign LK 2 (Wink)
Program 14-05-01
Trunks 5 ~ 28
Assign Trunk Group 11
Trunks 29
~ 52
Assign Trunk Group 10
Program 34-01-01
Trunks 5
~ 28
Assign LK 2 (Wink)
Program 22-02-01
Trunks 5
~ 52
Assign LK 6 (Tie Line)
Program 34-01-01
Trunks 5
~ 52
Assign LK 2 (Wink)
For CCISoIP only
System A System B System C
Program 14-13-01
Select Trunk Group 10
Assign CCIS Route ID 1
Program 44-05-10
F-Route Table 1 : 3
F-Route Table 2 : 4
Program 44-05-10
F-Route Table 1 : 2
F-Route Table 2 : 4
Program 14-14-01
Trunks 9
~ 32
Assign CIC 1
~ 24
Program 14-13-01
Select Trunk Group 10
Assign CCIS Route ID 1
Program 50-01-01
Enable CCIS
Program 50-01-01
Enable CCIS
Program 14-14-01
Trunks 5
~ 28
Assign CIC 1
~ 24
Program 50-02-03
Route ID 9 : 3
Program 50-02-01
Select CCIS Route ID 1
Assign Channel Port 28
Program 50-01-01
Enable CCIS
Program 50-03-01
System ID 1 : 2
System ID 2 : 4
System A System B System C
