Issue 2.0

SV9100 Networking Manual 8-41

The following table shows the common IP Precedence/Diffserv values and their

hexadecimal equivalent.

Table 8-2 Common IP Precedence/Diffserv Values and Hexadecimal Equivalent

IP Precedence

Name

Hex Value

IP Precedence 1 20

IP Precedence 2 40

IP Precedence 3 60

IP Precedence 4 80

IP Precedence 5 A0

IP Precedence 6 C0

IP Precedence 7 E0

DSCP

Name

Hex Value

DSCP 10 28

DSCP 12 30

DSCP 14 38

DSCP 16 40

DSCP 18 48

DSCP 20 50

DSCP 22 58

DSCP 24 60

DSCP 26 68

DSCP 28 70

DSCP 30 78

DSCP 32 80

DSCP 34 88

DSCP 36 90

DSCP 38 98

DSCP 46 B8

DSCP 48 C0

DSCP 56 E0
