Issue 2.0
5-34 SV9100 IP K-CCIS
3.1.3 VoIP Address Assignments
This example shows VoIP address assignments made for systems A and
B.
3.1.4 IP K-CCIS Availability
This example shows IP K-CCIS availability assignments made for systems
A and B.
3.1.5 IP K-CCIS Assignment
This example shows IP K-CCIS assignments made for systems A and B.
System A System B
Program 10-12-09
IPL IP Address: 192.168.1.10
Program 84-26-01
Slot 1, Assign IP Address
GW: 192.168.1.11
Program 10-12-09
IPL IP Address: 192.168.1.20
Program 84-26-01
Slot 1, Assign IP Addresses
GW: 192.168.1.20
System A System B
Program 50-01-01
Select Option 1 (Enable)
Enables the CCIS Feature
Program 50-01-01
Select Option 1 (Enable)
Enables the CCIS Feature
Program 50-02-03
Assign Route ID 9 = 01
(Route ID 9 is designated for Host
Originating Point Code)
Program 50-02-03
Assign Route ID 9 = 02
(Route ID 9 is designated for Host
Originating Point Code)
System A System B
Program 50-03-01
System ID 1
~ 255 – Enter Destination
Point Code
System ID 1 = DPC 02
Program 50-03-01
System ID 1
~ 255 – Enter Destination
Point Code
System ID 1 = DPC 01
Program 50-03-03
System ID 1
~ 255 – Enter Destination
System IP Address.
System ID 1 = 192.168.1.20
Program 50-03-03
System ID 1
~ 255 – Enter Destination
System IP Address
System ID 1 = 192.168.1.10
To Next Page
