2.3.3 IP Address of other systems within the network
° 10-27 : IP System ID - IP Address
The IP Addresses of all other systems within the network must be defined in this program. Each system is
identified by a 'System Number' (1 to 50), this is used within the numbering plan to route calls to another
system.
Example:
2.3.4 Networking TCP Port
° 10-20-01 : LAN Setup for External Equipment - TCP Port
Define the TCP port number for communicating to external equipment. The port number defined should be the
same in each networked system.
System ID 01-50
Item
No.
Item Input Data Default
Related
Program
01
IP Address
System ID is related
with the System ID in
the Numbering Plan
(Program 11-01-03).
When the digits are ana-
lyzed and the system ID
is determined from the
system data set in the
Numbering Plan, the
Networking call will be
sent to the IP Address
set in this program.
The IP Address should
be the IP Address of the
peer GCD-CP10 (Pro-
gram 10-12-01).
1.0.0.1 - 126.255.255.254
128.1.0.1 - 191.254.255.254
192.0.1.1 - 223.255.254.254
0.0.0.0 11-01-03
10-12-01
02
Call Procedure Port
The Port Number should
be set with the same
value as the H.225 setup
port in Program 84-02-
33.
1-65535 1730 84-02-33
System – A System – B
System ID: 1 System ID: 1
IP Address: 172.16.5.10 IP Address: 172.16.0.10
Port: 1730 Port: 1730
