2.4 AspireNet Multi Site
AspireNet Multi Site is a network of three or more systems connected by either AspireNet ISDN
or AspireNet IP. The configuration for three or more sites is the same as for two sites, refer to
AspireNet ISDN or AspireNet IP for details of setting up the SV9100 systems.
The example below shows three systems, each has a IPLE Blade installed.
The IPLE Blade in each system are connected to an Ethernet hub.
System A has extension numbers in the range 200-299, system B has 300-399 and system C
has 400-499.
System Configuration
• All systems within the network must have a direct connection to all other systems in the
network.This makes AspireNet IP the more practical type for Multi Site networks.
• IPLE Resource will be used at each system when a call is transferred. For example a call that
originates from site A and calls site B is held and transferred to site C will use IPLE resources at
all three sites.
System A System B System C
Ethernet Hub
System A System B System C
IPLA IP Address
172.16.0.10
IPLA IP Address
172.16.0.11
IPLA IP Address
172.16.0.12
Address for
Remote System
System 01 =
172.16.0.11
System 02 =
172.16.0.12
Address for
Remote System
System 01 =
172.16.0.10
System 02 =
172.16.0.12
Address for
Remote System
System 01 =
172.16.0.10
System 02 =
172.16.0.11
System
Numbering Plan
Dial 2x =
Intercom
Dial 3x =
Networking
Dial 4x =
Networking
System
Numbering Plan
Dial 2x =
Networking
Dial 3x =
Intercom
Dial 4x =
Networking
System
Numbering Plan
Dial 2x =
Intercom
Dial 3x =
Intercom
Dial 4x =
Networking
VoIP Gateway IP
Address
172.16.0.21
VoIP Gateway IP
Address
172.16.0.22
VoIP Gateway IP
Address
172.16.0.23
