Issue 2.0
12-2 All DSP Busy Indication
Alarm Report Example:
The report example below shows an alarm for all busy Station and Trunk DSPs.
LCD Display
SECTION 2 SERVICE CONDITIONS
When using IP Phones, the alarm is shown on both terminals involved in that call if
they are both on the same system, this includes NetLink systems.
The alarm cannot be displayed on Standard SIP Phones, Soft Phones or Single
Line phones.
If a call from a Standard SIP telephone to a Multiline telephone cannot be
established due to an All DSP Busy condition, the Multiline telephone will not
display the “All DSP” busy message.
If a SIP trunk call is sent to the SV9100 when all DSP resources are busy, the call is
rejected but the alarm is not displayed on any system telephone.
The default alarm setting is Minor.
If an all DSP condition is encountered when making a call across a CCISoIP
Network, only the calling stations receives the alarm indication.
<< ALARM REPORT >> 01/22/2009 23:37
LVL NO STAT DATE TIME ITEM UNIT SLT PRT PARAMETER
-------------------------------------------------------------------------------
MAJ 0068 ERR 01/22/09 09:30 VoIP All DSP Busy VoIPDB 01 00 STA
MAJ 0068 ERR 01/22/09 09:31 VoIP All DSP Busy VoIPDB 01 00 TRK
MIN 0002 REC 01/22/09 09:32 PKG Installation PRIU 02 00
LCD Display Indication Note
Clock/Calendar Non-NetLink System
XX = Slot number of CCPU with IPLE blade.
VoIP DSP All Busy XX
Soft Key
Clock/Calendar NetLink System
YY = System ID
XX = Slot number of CCPU with IPLE blade.
VoIP DSP All Busy YY-XX
Soft Key
