Chapter 17 Files

1038

Saving Files Recalled by Autoload

• To select a single file, press the arrow keys to scroll the reverse video

cursor, or directly press on the list in the status area.

Press [tSave].

The data from the selected registers is saved in the specified destination.

If the specified destination already contains data, a confirmation message

appears.

• Select “Yes” to overwrite the existing data.

• Select “No” to cancel the entire saving operation.
