Chapter 19 Control Panel Setup (Panel)
1135
Overall Control Panel Settings (Config Menu)
1
In the Panel >Config menu, press [Link/Program Button].
The Link/Program Button menu appears.
2
Press [Xpt Module].
The Xpt Module menu appears.
3
Select the bank in the status area.
4
Select [Aux Ctrl/
Aux Disply] in the <PRE MCRO
/POST MCRO> group
.
This assigns the Aux Ctrl function to the [PRE MCRO] button, and the
Aux Display function to the [POST MCRO] button.
Assigning Keys to the DSK1 and DSK2 Buttons in the
Downstream Key/Fade-to-Black Control Block
It is possible to select the key used for downstream key/fade-to-black control
block operations.
For details of the downstream key/fade-to-black control block, see Chapter 2
(Volume 1).
1
In the Panel >Config >Link/Program Button menu, press [DSK/FTB
Module].
The DSK/FTB Module menu appears.
The left side of the status area shows the DSK1 and DSK2 buttons, and the
right side shows a list of keys to be assigned.
2
Press the indication (DSK1, DSK2) of the button for the assignment.
The button you pressed changes to reverse video.
3
Using any of the following methods, select the key to be assigned.
• Press directly on the list.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
Knob Parameter Adjustment Setting values
1 Key No Selection of key assigned to
button
1 to 16
To Next Page
