Chapter 1 MVS-8000 Functions
43
Basic Video Processing
Side Flags
The term “side flags” refers to the areas to left and right of an image with aspect
ratio 4:3 embedded within a 16:9 frame, when these areas are filled with a
separate image selected from the utility 1 bus.
For details, see “Side Flags” (page 484).
Multi Program 2
By operating the switcher in Multi Program 2 mode, a single switcher mix/
effects bank can be used to create two separate video outputs, referred to as
“main” and “sub.” You can set backgrounds, keys, and transitions for each of
main and sub. For example, immediately after a score in baseball two versions
of the scene can be provided as shown below, and switched simultaneously.
Input source with aspect ratioImage to fill the side flag
areas (selected from utility 1
bus)
Turn the side flag
function on
Side flag area
Side flag area
