Chapter 19 Control Panel Setup (Panel)
1126
Overall Control Panel Settings (Config Menu)
Linking the Next Transition Selection Buttons
To the transition links between keyers, you can add a link for the next transition
selection buttons in the transition control block. The effect of this additional
link is such that if for example, two keyers (Key 2 and Key 3) are linked with
the master keyer (Key 1), pressing the [KEY1] next transition selection button
also selects the [KEY2] and [KEY3] buttons.
1
Set the transition links between keyers.
For details of the operation, see the previous section “Linking Transitions
Between Keyers.”
2
Press [Next Trans Link], turning it on.
The [KEY1], [KEY2], [KEY3], and [KEY4] next transition selection
buttons in the transition control block are now selected coupled to the
settings in the Key Trans Link menu for transition links between keyers.
Notes
These settings apply to the whole Key Trans Link menu. It is not possible
to make separate settings for each master keyer.
Selecting the Module to be the Reference for Device
Control Block
In the <Reference Module> group of the Panel >Config menu, select the
module to be the reference.
• Trackball
• Joystick
Assigning a Region to the Region Selection Buttons in
the Numeric Keypad Control Block or Multifunction
Flexi Pad Control Block
You can set a maximum of four regions to each of the region selection buttons
in the numeric keypad control block or Multifunction Flexi Pad control block.
In the Multifunction Flexi Pad control block, pressing the region selection
button [MORE] displays the regions not assigned to the region selection
To Next Page
