Chapter 18 System Setup (System)
1097
Installation and Device Setup (Install/Unit Config Menu)
To prepare a texture file
Create a texture file meeting the following conditions, and save it on a memory
card.
File format: Windows bmp (“bitmap”) (extension: bmp, 24-bit RGB)
File name: alphanumeric (maximum 8 characters) + extension (bmp)
Example: wood_01.bmp
Image size (horizontal × vertical): 128 × 128 to 1024 × 1024 pixels
The maximum number of texture files that can be handled by the system is
related to the image size of the texture files, as shown in the following table
(when all images are the same size).
Notes
• Different image sizes can be combined, but this affects the total number of
texture files that can be handled.
• The number of texture files that can be handled may be reduced, depending
on the way in which they are stored in memory (see “Texture Package
menu” (page 1098)).
• For a texture file with an image size outside the specification, the minimum
enclosing image size is applied (see table above), and the region below and
to the right is filled with black.
Example: a 300 × 200 pixel texture file is treated as 512 × 256 pixels.
Maximum number of texture files handled
Dimension (horizontal)
Dimension (vertical)
128 pixels 256 pixels 512 pixels 1024 pixels
128 pixels 64 32 16 8
256 pixels 32 16 8 4
512 pixels 16 8 4 2
1024 pixels 8421
