Chapter 19 Control Panel Setup (Panel)
1151
Cross-Point Settings (Xpt Assign Menu)
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
5
Using the buttons in the <Xpt Assign> group, assign the selected signal to
the button number currently selected in the main table.
Set: Delete the signal currently assigned to the selected button number and
make a new assignment.
Insert: Move down one line the signal currently assigned to the selected
button number and following signals, and make a new assignment.
Notes
When a button number in the range 121 to 128 is selected, execution of
“Insert” is impossible. The signal assignments to button numbers 121 to
128 cannot be changed. When “Insert” is executed for any other number,
moving down of signals ends at number 120, and the signals assigned to
numbers 121 to 128 are maintained in their original lines.
To disable a button
In the Panel >Xpt Assign >Main, V/K Pair Assign menu, select the button you
want to disable, and press [Inhibit].
To delete any currently assigned signal
In the Panel >Xpt Assign >Main, V/K Pair Assign menu, select the button
corresponding to the signal you want to delete, and press [Delete] in the <Xpt
Assign> group.
Signal deletion is executed in accordance with the selection in the <Assign>
group, and the signal assigned to the button number next to the selected button
number and following signals move up one line.
Notes
When a button number in the range 121 to 128 is selected, execution of
“Delete” is impossible. The signal assignments to button numbers 121 to 128
cannot be changed. When a signal assigned to any other button number is
deleted, moving up of signals ends when the signal assigned to number 120 has
moved to number 119, and the signals assigned to numbers 121 to 128 are
maintained in their original lines.
Knob Parameter Adjustment Setting values
3 Source No Selection of source to be assigned 1 to 128
