Chapter 19 Control Panel Setup (Panel)
1161
Auxiliary Bus Control Block Settings (Aux Assign Menu)
a) The setting can be from 1 to 62. The valid settings, however, depend on the number of
buttons and the delegation button shift mode.
b) The buses that can be assigned are as follows.
AUX1 to AUX48, Monitor1 to Monitor8, DME1V to DME8V, and DME1K to DME8K
M/E1 Utility1 and 2, M/E2 Utility1 and 2, and M/E3 Utility1 and 2
P/P Utility1 and 2, Frame Memory Source1 and 2, Edit Preview, DSK1 to 4 Fill/Source,
M/E-1 Key 1 to 4 Fill/Source, M/E-2 Key 1 to 4 Fill/Source, and M/E-3 Key 1 to 4 Fill/
Source
M/E-1 EXT DME, M/E-2 EXT DME, M/E-3 EXT DME, P/P EXT DME, DME Utility
1 and 2, and CCR 1 and 2
• For a button for which you want to disable operation, press [Inhibit].
2
Press [Set] to confirm the selection.
To set the AUX delegation button shift operation
To set the operation mode of the rightmost button in the row of AUX
delegation buttons, select one of the following in the <Shift Mode> group of
the Panel >Aux Assign menu.
Hold: Acts as a shift button, and the shifted version of the AUX delegation
buttons is enabled while the button is held down.
Lock: Acts as a shift button, and pressing the button toggles between the
shifted version and the unshifted version of the AUX delegation buttons.
Off: Acts as an AUX delegation button. In a 16-button system it acts as button
number 16, in a 24-button system as button number 24, and in a 32-button
system as button number 32.
Knob Parameter Adjustment Setting values
1 Deleg No Selection of AUX delegation
button
1 to 128
a)
2 Bus No Selection of bus to be assigned
1 to 123
b)
Number of buttons Shift mode Valid settings
16 OFF 1 to 16
ON 1 to 30
24 OFF 1 to 24
ON 1 to 46
32 OFF 1 to 32
ON 1 to 62
To Next Page
