Chapter 19 Control Panel Setup (Panel)
1170
Setting Button Assignments (Prefs/Utility Menu)
a) For the safe title on/off commands (from ME1 PGM1 ST-ME1 PGM4 ST to AUX1 ST-AUX48
ST), the name of the assigned output signal is shown.
Assigning a menu shortcut to a user preference button
1
Referring to the procedure up to step 2 of “Assigning Functions to User
Preference Buttons” (page 1166), select [Menu Shortcut].
The user preference buttons [PREFS 1] to [PREFS 16] flash amber.
2
Using any of the following methods, display the menu to which you want
to make a shortcut.
• In the menu control block, press the relevant top menu selection button,
then select VF and HF.
• Press the menu page number button in the upper left corner of the menu
screen, then enter a menu number from the numeric keypad window.
Post Macro Set macro attachment in post macro
mode
Can be set only
while pressed (lit)
When the function
is assigned
Macro Take Macro execution During execution When the function
is assigned
Macro Auto Ins Macro auto insert mode on/off On Off
Macro AT with Rate When registering an auto transition
macro event, on/off setting of mode to
save transition rate
On Off
Macro AT with A/B Bus When registering an auto transition
macro event for the transition control
block, on/off setting of mode to save A/
B Bus cross-point settings
On Off
Macro TL with Region When registering a timeline macro
event, on/off setting of mode to save
applicable region
On Off
DME Override DME override on/off On Off
DME Graphic DME graphics on/off (Applies to
graphics for channel selected in device
control block)
On Off
System Manager Enbl Enable/disable operation from System
Manager
Enabled Disabled
Plug-In Editor Enbl Enable/disable operation from an
editing keyboard
Enabled Disabled
Inhibit Set Inhibit cross-point button Can be set only
while pressed (lit)
When the function
is assigned
Inhibit All Clear Clear all cross-point button inhibit
settings
Can be set only
while pressed (lit)
When the function
is assigned
Command name
a)
Function Button status
Lit amber Off
