Chapter 20 Switcher Setup (Switcher)
1208
Settings for Switcher Configuration (Config Menu)
Notes
These settings are valid only on the MVS-8000A/8000G; not valid on the
MVS-8000.
For details of side flag operations, see “Side Flag Settings” in Chapter 10
(Volume 1).
Setting the aspect ratio (4:3/16:9)
1
In the Switcher >Config menu, press [Side Flags].
The Side Flags menu appears.
The status area lists the video/key pair numbers, video signal source
names, and aspect ratio settings (16:9/4:3).
2
Using any of the following methods, select the pair number for which you
want to make the setting.
• Press directly on the list in the status area.
• Use the arrow keys to scroll the reverse video cursor.
• Turn the knobs.
• To select all of the pair numbers, press [ALL].
3
In the <Aspect> group, press [4:3].
If you select [16:9], no side flags are applied.
To set 4:3 video material to have side flags applied automatically
You can make a setting so that when a signal with aspect ratio set to 4:3 is
selected in the cross-point control block, side flags are automatically applied.
To do so, in the Switcher >Config >Side Flags menu press [Auto Side Flags].
Pressing this button toggles the setting on and off.
This setting applies to all of the M/E and PGM/PST banks.
To set to crop to 4:3 when a DME wipe is executed
When side flags are enabled, you can automatically crop an image as set to be
a 4:3 image when executing a DME wipe.
To do so, in the Switcher >Config >Side Flags menu press [Auto Crop].
Pressing this button toggles the setting on and off.
This setting applies to all of the M/E and PGM/PST banks.
Knob Parameter Adjustment Setting values
1 V/K Pair No Selection of a V/K pair by its
number in the list
1 to 128
3 Num Selection of number of V/K pairs
in the list
1 to 128
