Chapter 20 Switcher Setup (Switcher)
1219
Signal Input Settings (Input Menu)
Making cross-conversion settings
To make the cross-conversion settings, carry out steps 1 and 2 described in
“Making detailed settings for up-conversion” (page 1214). No other settings
are required.
Copying format converter input data
1
In the Switcher >Input >FC Adjust menu, press [Copy].
The Copy/Swap >Copy >Format Converter menu appears.
The status area shows lists of the copy source on the left, and the copy
destination on the right.
2
Select [Input] in the <Data Select> group.
3
Using any of the following methods, select the data.
• Press directly on the list.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
4
Press [Copy].
This copies the data.
Knob Parameter Adjustment Setting values
1 Left No Select the copy source data 1 and upwards
2 Right No Select the copy destination data 1 and upwards
3 Num Select the number of items 1 and upwards
To Next Page
