Chapter 20 Switcher Setup (Switcher)
1240
Settings Relating to Function Links (Link Menu)
The M/E Link menu appears.
The status area displays a link list showing link source banks (M/E and
PGM/PST) and link destination banks, and a selection list.
2
Using any of the following methods, select the link number you want to
set.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
3
In the <M/E Select> group, select [Master M/E] (link source).
4
Using any of the following methods, select the M/E or PGM/PST bank you
want to be the link source, then press [M/E Set].
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knob.
a) 1: M/E-1
2: M/E-2
3: M/E-3
4: PGM/PST
5
In the <M/E Select> group, select [Linked M/E] (link destination).
6
In the same way as in step 4, select the M/E or PGM/PST bank you want
to be the link destination, then press [M/E Set].
To link the banks not only for transition execution but also for the
other operations
Press [Transition Only] and turn it off.
To release the link setting
Use the same operation as in step 2 to select the link number for which you
want to release the link setting, then press [Clear].
Knob Parameter Adjustment Setting values
1 Link No Link number selection 1 to 8
Knob Parameter Adjustment Setting values
2 No Bank selection
1 to 4
a)
