Chapter 22 DCU Setup (DCU)
1274
GPI Output Setting (GPI Output Assign Menu)
a) 1: Field 1, 2: Field 2, 3: Any
When “ ” is selected as the trigger polarity, there is no Pulse Width
setting. When “Status” is selected, there is no Pulse Width or Timing
setting.
4
In the <Source Device> group, select the control panel or DCU to handle
the GPI output.
SCU1: ID1 control panel (PNL1)
SCU2: ID2 control panel (PNL2)
SCU3: ID3 control panel (PNL3)
DCU1: ID1 DCU
DCU2: ID2 DCU
When the action set in the following step 5 is carried out on the control
panel selected here, this causes a GPI output. It is also possible to output
error information. When the DCU is selected, you can output error
information by means of the action set in step 5.
5
Using any of the following methods, select the action you want to set.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knobs.
a) • Action list when the trigger type is other than “Status”
When Source Device is SCU: M/E1 Key1 SS ? Recall, M/E1 Key2 SS ? Recall, M/E1
Key3 SS ? Recall
M/E1 Key4 SS ? Recall, M/E2 Key1 SS ? Recall, M/E2 Key2 SS ? Recall, M/E2
Key3 SS ? Recall, M/E2 Key4 SS ? Recall
M/E3 Key1 SS ? Recall, M/E3 Key2 SS ? Recall, M/E3 Key3 SS ? Recall, M/E3
Key4 SS ? Recall
P/P DSK1 SS ? Recall, P/P DSK2 SS ? Recall, P/P DSK3 SS ? Recall, P/P DSK4
SS ? Recall
Editor GPI-?? (executable only when the BZS-8050 license is valid)
No Action
When Source Device is DCU: No Action
Knob Parameter Adjustment Setting values
3 Pulse Width Pulse width 1 to 60 (fields)
4 Timing Output timing
1 to 3
a)
Knob Parameter Adjustment Setting values
2 Action Action selection
1 and upwards
a)
5 Reg No Snapshot register number
1 to 4
b)
5 GPI No GPI number selection
1 to 32
c)
To Next Page
