Appendix (Volume 3)
1320
Data Saved by [Setup Define] and [Initial Status Define]
Included in
Panel
— — • Downstream Key/Fade-to-Black
Control Block:
[DSK1], [DSK2], [K-SS], key source
name display/key snapshot buttons,
Edit PVW Shift ON/OFF
• Multifunction Flexi Pad Control Block:
[WIPE], [DME WIPE], [SNAP SHOT],
[EFF], [SHOT BOX], [MCRO], [TRANS
RATE], [KEY ADJ], [KEY SS], memory
recall buttons
3211 Misc >Enable >Port
Enable >System Manager
All data relating to System Manager
menu
3212 Misc >Enable >Plug-In
Editor
All data relating to Plug-In Editor menu
6351 Snapshot >Key Snapshot
>Attribute
Settings of <Recall Mode> group
Included in
Switcher
(Same as
data saved in
Snapshots)
b)
— — • For each M/E, setting data relating to
the following:
cross-points, transitions, Key1 to Key4
(including settings in the independent
key transition control block), wipes,
DME wipes, video processing
• Color backgrounds 1/2
• Frame memory
• AUX bus (including video processing
settings)
• Monitor bus
3213 Misc >Enable >Side Flags All data relating to Side Flags menu
3211 Misc >Enable >Port
Enable
Setting data for <Switcher> group
Included in
DME
4100 DME >Status Three-dimensional transformation data
4111 DME >Edge >Border/
Crop
All data relating to Border/Crop menu
4112 DME >Edge >Beveled
Edge
All data relating to Beveled Edge menu
4121 to 4124 DME >Video Modify All data relating to Video Modify menu
4131 DME >Freeze >Freeze All data relating to Freeze menu
4141 (4141.1
to 4141.28)
DME >Non Linear All data relating to Non Linear menu
4151 DME >Light/Trail >Lighting All data relating to Lighting menu
4152 DME >Light/Trail >Trail All data relating to Trail menu
4153 DME >Light/Trail >Motion
Decay
All data relating to Motion Decay menu
4154 DME >Light/Trail >KF
Strobe
All data relating to KF Strobe menu
Type Menu number Menu path Saved data
To Next Page
