Sony MVS-8000 User Manual

Chapter 6 DME Wipes
373
DME Wipe Pattern Operations in the Multifunction Flexi Pad Control Block
Buttons for setting DME wipe pattern cropping
CROP: Adjusts the DME wipe pattern cropping.
4:3 CROP: Crops a 16:9 image to 4:3.
When the [CROP] button is lit green, you can set the cropping ratio of the DME
wipe pattern, with the control knobs.
Button for specifying effect size
SIZE: Specifies the effect size. When the [SIZE] button is lit green, you can
specify the effect size, with the control knobs.
a) The effect size when [Size] is off is taken as 100.00.
DME wipe modify clear
With the [DME WIPE] button held down, pressing and holding down the
region selection button for the selected region returns the DME wipe settings
to their initial status.
For details of the initial status, see “Selecting the State After Powering On
(Start Up Menu)” in Chapter 18 (Volume 3).
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 H Cropping ratio of the image
from left and right sides
–100 to +100
2 V Cropping ratio of the image
from top and bottom sides
–100 to +100
3 A Cropping ratio of the image
from all four sides
–100 to +100
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 T Cropping ratio of the image
from the top
–100 to +100
2 L Cropping ratio of the image
from the left
–100 to +100
3 R Cropping ratio of the image
from the right
–100 to +100
4 B Cropping ratio of the image
from the bottom
–100 to +100
Knob Parameter Adjustment Setting values
1 S Effect sizes
0 to 200
a)
