Chapter 7 Frame Memory
377
Overview
SD system:
(Without ancillary data)
(With ancillary data)
Notes
For the MVS-8000A and MVS-8000G, up to two frame memory boards can be
installed (MKS-8440A for the MVS-8000A, MKS-8442G for the MVS-
8000G). The above-stated maximum number applies when one frame memory
board is installed.
When two boards are installed, the figures are doubled, but of the two boards
only one can be used for frame memory clips.
Note that for the MVS-8000/8000SF, MVS-8000ASF and MVS-8000GSF, it
is not possible to install two frame memory boards.
For details of operating procedures, see “Still Image Operations” (page 380).
Types of image and terminology used
The following types of image are handled in frame memory.
Freeze image: An input image that has been frozen, but not saved to memory.
Still image: A freeze frame that has been saved to memory as a file. Each file
(still file) holds just one still image.
Frame memory clip: A clip consists of a sequence of still images, which
appears as a movie on playback. In this manual this is also referred to
simply as a “clip.” The files (still files) constituting clips are referred to as
a “clip file.”
When the above distinctions are not being made, an image is simply referred
to as an “image.”
1080PsF/30 Approx. 800 frames
720P/50 Approx. 1400 frames
720P/59.94 Approx. 1700 frames
Video format Memory capacity
480i/59.94 Approx. 5600 frames
576i/50 Approx. 4800 frames
Video format Memory capacity
480i/59.94 Approx. 4700 frames
576i/50 Approx. 3900 frames
Video format Memory capacity
