Chapter 7 Frame Memory
400
Still Image Operations
The name of each image recorded in this way consists of a first character string
followed by a second string.
First character string: A common part of name assigned to all the still images
captured in one record operation. This string includes a maximum of four
characters, which can be specified using a menu before carrying out the
capture. The first string is automatically used as the clip name when the
images are treated as a frame memory clip.
Second character string: A four-digit number (0000 or greater), which is
incremented each time a still image is captured.
Notes
• When using the record function to continuously capture frames, it is not
possible to use the mask function.
• On the MVS-8000, the image file name is “anmxxyyy” (“anm” is constant,
“xx” is a two-digit number from 00 to 99 incremented by 1 for ever recording
operation, and “yyy” is a three-digit number from 000 to 999, incremented
by 1 for each captured image).
Continuously freezing input images and writing to memory
1
In the Frame Memory menu, select VF1 ‘Still’ and HF4 ‘Animation
Record.’
The Animation Record menu appears.
2
Select the desired frame memory.
For details of the operating procedures, see “Selecting outputs (FM) and
target frame memory” (page 385).
3
To use V/K mode, press [V/K Mode], turning it on.
4
Press a button in the frame memory folder selection area, to select the
folder to hold the freeze image.
For details of the selection method, see page 386.
Notes
The folder selected here is the destination folder for writing the freeze
image.
It is not possible to change the selection of this folder after the following
step 5.
An orange bar appears on the selection button for the destination folder.
To Next Page
