Chapter 10 Special Functions
503
Multi Program 2
• If a snapshot is recalled simultaneously for main and sub, or a keyframe is
executed simultaneously for main and sub, then for the following common
to main and sub the main settings are reflected.
–Key
–M/E Config
– DME external video bus and utility 1 bus
• When a macro attachment is set on the DME utility 1 bus or DME utility 2
bus, it is not possible to make separate main and sub settings.
• When snapshots with different M/E Config settings are recalled:
– If M/E Config data is not to be included in the snapshot data, the current
system settings are used for snapshot reproduction.
– If M/E Config data is to be included in the snapshot data and if it was
created before Version 5.30, then standard mode is used. If created in
Version 5.30 or later, first M/E Config data is set, and then other snapshot
data is recalled.
• The bus override function is only available on the following buses:
– M/E-1 to M/E-3 Main BKGD A/B buses
– M/E-1 to M/E-3 Sub BKGD A/B buses (UTIL-2, UTIL-3 buses)
– P/P Main PGM/PST bus
– P/P Sub PGM/PST buses (UTIL-2, UTIL-3 buses)
• When a master snapshot or master timeline is executed with a key being
assigned to both main and sub, it is uncertain which data will be reflected.
• When recalling a master snapshot with different register numbers for main
and sub, the recall timing may differ by one field or more between main and
sub.
• The link state is maintained even when M/E Config is changed. Set the link
setting again, as required.
• Since keys 2 to 4 are shared between main and sub, when the main and sub
fader lever positions are different, if you move the fader lever, the video
changes instantaneously to the value of the most recently moved fader lever.
• When the transition type for main or sub is set to preset color mix, it is not
possible to carry out independent key transition operation (common to main
and sub).
