Chapter 11 DME Operations

598

DME Special Effect Operations

Beveled Edge

(See page 616.)

Gives an image a beveled edge. You can set the edge width and color. The

inner edge softness and edge boundary softness can also be set.

Key Border

(See page 618.)

Adds borders to keys or gives a key consisting of an outline only.

Name Effect/Image

Color Lights

default chapter1
- Control Panel: Example Configuration1
- Control Panel: Example Configuration3
- Table of Contents6
