Chapter 11 DME Operations
617
DME Special Effect Operations
•4:3 mode
• 16:9 mode
4 In the <Edge Mode> group, select the type of edge.
Light: effect of light striking the edge
Color: colored edges. When this is selected, set the following parameters
in the <Color Adjust> group.
•To set the density
• To set the colors for each edge (Top, Left, Right, Bottom, All)
a) For the All adjustment, the value for Left is shown.
Knob Parameter Adjustment Setting values
1 H Simultaneously adjust width of left
and right edges
0.00 to 4.00 (SD)
0.00 to 12.00 (HD)
2 V Simultaneously adjust width of top
and bottom edges
0.00 to 3.00 (SD)
0.00 to 9.00 (HD)
3 All Simultaneously adjust width of all
four edges
Value of H shown
Knob Parameter Adjustment Setting values
1 H Simultaneously adjust width of left
and right edges
0.00 to 4.00 (SD)
0.00 to 16.00 (HD)
2 V Simultaneously adjust width of top
and bottom edges
0.00 to 2.25 (SD)
0.00 to 9.00 (HD)
3 All Simultaneously adjust width of all
four edges
Value of H shown
Knob Parameter Adjustment Setting values
1 Top Adjust luminance of top edge –100.00 to +100.00
2 Left Adjust luminance of left edge –100.00 to +100.00
3 Right Adjust luminance of right edge –100.00 to +100.00
4 Bottom Adjust luminance of bottom edge –100.00 to +100.00
5 All Simultaneously adjust luminance of
all four edges
Value of Left shown
Knob Parameter Adjustment Setting values
1 Density Adjust the color density 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Luminance Luminance
0.00 to 100.00
a)
2 Saturation Saturation
0.00 to 100.00
a)
3Hue Hue
359.99 to 0.00
a)
