Sony MVS-8000 User Manual

Chapter 2 Menus and Control Panel
66
Names and Functions of Parts of the Control Panel
Move the fader lever to the position of
a particular pattern size, and stop it
there, then press this button to set the
pattern limit range.
When the VTR/disk recorder/frame
memory operation mode is enabled in
setup, pressing this button stops the
tape.
g KF (keyframe) button
When the VTR/disk recorder/frame
memory operation mode is enabled in
setup, pressing this button cues the tape
automatically to the start point. When not,
pressing this button to turn it on allows you
to use the fader lever as a keyframe fader.
h Key status display
For each of keys 1 to 4, the corresponding
ON indicator lights when the key is
inserted. It also shows the priority (1 to 4)
of each key.
i PRIOR (priority) SET button
While this button is held down, you can set
the key priority.
The setting mode when this button is
pressed depends on whether or not the
[KEY PRIOR] button is lit, as follows.
• When the [KEY PRIOR] button is off, the
current key priority is set.
• When the [KEY PRIOR] button is lit, the
key priority after the next transition is set.
Press the [KEY PRIOR] button as required,
to switch between these two modes.
In either mode, hold down the [PRIOR
SET] button, and press the button ([KEY1]
to [KEY4]) corresponding to the key you
want to bring to the front.
The following controls are used as the
independent key transition control block.
j Key delegation buttons
These buttons delegate this independent
key transition control block to a desired
keyer. Press one of the [KEY1] to [KEY4]
buttons ([DSK1] to [DSK4] in the PGM/
PST bank), turning it on.
You can press more than one button to
select two or more keyers.
While these buttons are held down, you can
select a key source with the cross-point
buttons for the key bus.
Pressing one of these buttons twice in rapid
succession changes its state so that you can
make cross-point selections on the
corresponding key bus.
a) The key bus selection button [KEY3] in the cross-
point control block goes off.
b) The key bus selection button [KEY4] in the cross-
point control block goes off.
c) The key bus selection button [KEY3] in the cross-
point control block lights.
d) The key bus selection button [KEY4] in the cross-
point control block lights.
k Independent key transition type
selection buttons
Press one of the following buttons, turning
it on, to select the independent key
transition type.
MIX: Faded in or out.
WIPE: Inserted or deleted with a wipe.
DME (DME wipe): Inserted or deleted
with a DME wipe.
l Independent key transition
execution section
KEY1 ON to KEY4 ON (DSK1 ON to
DSK4 ON in the PGM/PST bank)
buttons: Press the corresponding one
of these buttons to cut key 1 to key 4 in
or out instantaneously. When the key
Key delegation button
(double press)
Corresponding
key bus
[KEY1]
key 1
a)
[KEY2]
key 2
b)
[KEY3]
key 3
c)
[KEY4]
key 4
d)
