Sony MVS-8000 User Manual

Chapter 11 DME Operations
750
Global Effect Operations
Taking Ch1 Shadow as an example, the following explains the procedure for
applying the Drop Shadow effect.
1 Press [Ch1 Shadow], turning it on.
The Drop Shadow effect is enabled, and channel 2 becomes the channel for
the shadow to the image. You can adjust the position and density of the
shadow with the knobs.
Notes
The flex shadow function cannot be enabled when Drop Shadow is
enabled.
However, the flex shadow function is not supported on the MVE-8000/
8000A.
2 Set the parameters.
a) Setting for SD 4:3, SD 16:9
b) Setting for HD 4:3, HD 16:9
3 In the <Ch1 Shadow Source> group, select the shadow source signal.
Video: Select Ch2 video input as the shadow.
Flat Color: Select a matte color as the shadow.
4 When you select Flat Color in step 3, adjust the parameters.
Ch2+Ch3+Ch4 Valid Valid Valid
Ch1+Ch2+Ch3+Ch4 Valid Valid Valid Valid
Combiner channel
selection
Button
Ch1
Shadow
Ch2
Shadow
Ch3
Shadow
Ch1+Ch2
Shadow
Ch2+Ch3
Shadow
Knob Parameter Adjustment Setting values
1 Position H Horizontal shadow position
–8.00 to +8.00
a)
–32.00 to +32.00
b)
2 Position V Vertical shadow position
–8.00 to +8.00
a)
–32.00 to +32.00
b)
3 Density Density of shadow 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 359.99 to 0.00
