Chapter 19 Control Panel Setup (Panel)
1123
Overall Control Panel Settings (Config Menu)
This confirms the matrix selection and the selected part in the status area
returns to the previous color.
To delete a link
With the link selected, press [Clear].
Defining the position of a matrix
Specify where in the 1024 × 1024 S-Bus space the link matrix is to be provided,
by setting the source and destination start address.
For the matrix selected in the External Bus Link menu, use the following
procedure.
1
In the Panel >Config >Link/Program Button >External Bus Link menu,
press [Link Matrix Adjust].
The Link Matrix Adjust menu appears.
The status area shows the status of the currently selected matrix, and a list
of the source and destination start addresses that can be selected.
In this menu too, you can use the knobs to select the link for the setting.
2
Using any of the following methods, define the position of the matrix to be
linked.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knobs.
3
To confirm a source address selected in step 2, press [Source Set], to
confirm a destination address press [Destination Set], and to confirm a
level press [Level Set].
This confirms the selection, which is reflected in the status area.
Setting a link table
For the link selected in the External Bus Link menu, make the settings as
follows.
1
In the Panel >Config >Link/Program Button >External Bus Link >Link
Matrix Adjust menu, press [Link Table Adjust].
Knob Parameter Adjustment Setting values
2 Source Source start address 1 to 897
3 Destination Destination start address 1 to 897
4 Level Level 1 to 8
To Next Page
