Chapter 20 Switcher Setup (Switcher)
1228
Settings Relating to Video Switching (Transition Menu)
Setting the transition preview mode
To select the transition preview mode, in the <Transition Preview> group of
the Transition menu, select either of the following.
One Time: The transition preview ends after a single transition.
Normal: Switching the [TRANS PVW] button on or off switches between the
transition preview mode and the normal mode.
Selecting the transition mode of the independent key transition
control block
To select the key transition mode, select either of the following in the <Key
Transition> group of the Transition menu.
Same: The transition settings for the On and Off directions are the same.
Independ: The transition settings for the On and Off directions can be set
separately.
Selecting the background transition flip-flop mode
In the Transition menu, press [Bus Toggle], to switch between on and off.
On: Flip-flop mode
Off: Bus fixed mode
For more details, see “Fader Lever Operation in Bus Fixed Mode” in Chapter
3 (Volume 1).
Setting the split fader to be enabled or disabled
In the Transition menu, press [Split Fader] to switch between Enable and
Disable. This setting is only valid when using a simple transition module with
Bus Toggle set to Off.
Enable: When the fader lever is split, the split fader effect is enabled.
Disable: Even when the fader lever is split, the normal fader lever effect is
obtained.
Enabling or disabling the fade-to-black function
In the <FTB> group of the Transition menu, press the program output name to
toggle between On and Off.
On: When the [FTB] button is pressed, a fade-to-black is carried out.
Off: Even when the [FTB] button is pressed, no fade-to-black is carried out.
Notes
The PGM2 to PGM4 settings are only valid in Multi Program mode or DSK
mode.
