Chapter 20 Switcher Setup (Switcher)
1229
Settings Relating to Video Switching (Transition Menu)
Setting a preset color mix
1
In the Switcher >Transition menu, press [Preset Color Mix].
The Preset Color Mix menu appears.
The status area shows the stroke mode setting for each M/E bank, the
setting for whether or not the key status is maintained, and the one-time
mode setting.
2
In the <Stroke Mode> group, select whether to carry out a transition in one
stroke or two strokes.
Normal: Carry out a preset color mix with two transition operations.
Single: Carry out a preset color mix with a single transition operation.
Notes
In bus fixed mode (see page 1228), the setting is fixed to “Single.”
3
In the <Non Drop Key> group, select the key setting for a transition
including a key.
To carry out the transition with the key state maintained, press [Key1] to
[Key4], turning them on. (See “Transitions” in Chapter 1 (Volume 1).)
4
If each time a transition ends the transition type is to return to the previous
setting, press [One Time Enable].
Settings relating to fader lever operations
To select the way in which the fader lever position and the transition progress
are related, use the following procedure.
1
In the Switcher >Transition menu, press [Transition Curve].
The Transition Curve menu appears.
2
In the <Fader Curve> group, select the fader lever operation mode.
Normal: The transition progress is linear, according to the fader lever
position. (Factory default setting)
Adv Tally Mode: When the fader lever is moved from the end of its travel,
the tally is output slightly before the transition starts.
To Next Page
